Intel® Xeon W-3345 Processor 36M Cache, up to 4.00 GHz 24 Core
$2,751.00
Total Cores | 24 |
Total Threads | 48 |
Max Turbo Frequency | 4.00 GHz |
Processor Base Frequency | 3.00 GHz |
Cache | 36 MB |
Max # of UPI Links | 0 |
Bus Speed | 8 GT/s |
TDP | 250 W |
- Description
- Additional information
Description
Memory Specifications | |
Max Memory Size (dependent on memory type) | 4 TB |
Memory Types | DDR4-3200 |
Maximum Memory Speed | 3200 MHz |
Max # of Memory Channels | 8 |
Intel® Optane™ Persistent Memory Supported | No |
ECC Memory Supported ‡ | Yes |
Expansion Options | |
Scalability | 1S Only |
PCI Express Revision | 4 |
Max # of PCI Express Lanes | 64 |
Package Specifications | |
Sockets Supported | FCLGA4189 |
TCASE | 73°C |
Package Size | 77.5mm x 56.5mm |
Advanced Technologies | |
Intel® Speed Select Technology – Core Power | No |
Intel® Speed Select Technology – Turbo Frequency | No |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Speed Select Technology – Performance Profile | No |
Intel® Speed Select Technology – Base Frequency | No |
Intel® Resource Director Technology (Intel® RDT) | No |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 ‡ | No |
Intel® Turbo Boost Technology ‡ | 2 |
Intel® Hyper-Threading Technology ‡ | Yes |
Intel® Transactional Synchronization Extensions | Yes |
Intel® 64 ‡ | Yes |
Instruction Set Extensions | Intel® AVX-512 |
# of AVX-512 FMA Units | 2 |
Enhanced Intel SpeedStep® Technology | Yes |
Intel® Volume Management Device (VMD) | Yes |
Security & Reliability | |
Intel® Platform Firmware Resilience Support | No |
Intel® Total Memory Encryption | No |
Intel® AES New Instructions | Yes |
Intel® Software Guard Extensions (Intel® SGX) | No |
Intel® Trusted Execution Technology ‡ | Yes |
Execute Disable Bit ‡ | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology (VT-x) ‡ | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
Additional information
Server Brand Name | Intel |
---|---|
Processor Base Frequency | 3.0 GHz |
Total Cores | 24 Cores |
Socket type | FCLGA4189 |
TDP | 250 W |
